PWR-01 119
400W model
This section provides the specifications specific to the 400W model. For specifications com-
mon to all models (Protection functions, Signal output and input, Control functions, Other
functions, Operation display, Interface, and General), see "Common specifications"(p.128).
AC input
PWR401L PWR401ML PWR401MH PWR401H
Nominal input rating 100 Vac to 240 Vac, 50 Hz to 60 Hz, single phase
Input voltage range 85 Vac to 265 Vac
Input frequency range 47 Hz to 63 Hz
Current (TYP)
1
1. At the rated output power for the rated output current.
100 Vac 5.6 A
200 Vac 2.8 A
Inrush current 25 A or less
Power (MAX)
2
2. 100 Vac, at the rated output power.
560 VA
Power factor (TYP)
1
0.99 (input voltage: 100 V), 0.97 (input voltage: 200 V)
Efficiency (TYP)
1
75 %
Output hold time
2
20 ms or more
