Specifications ｜ Common specifications
General
400W model 800W model 1200W model
Weight (main unit only) Approx. 3 kg (6.61 lb) Approx. 5.5 kg
(12.13 lb)
Approx. 7.5 kg
(16.53 lb)
Dimensions See the outline drawing.
Environ-
mental
conditions
Operating environment Indoor use, overvoltage category II
Operating temperature 0 °C to +50 °C (32 °F to +122 °F)
Operating humidity 20 %rh to 85 %rh (no condensation)
Storage temperature -10 °C to +60 °C (14 °F to 140 °F)
Storage humidity 90 %rh or less (no condensation)
Altitude Up to 2000 m
Cooling method Forced air cooling using fan
Grounding polarity Negative grounding or positive grounding possible
Isolation voltage L/ ML/ MH type: ±500 Vmax
H type: ±800 Vmax
With-
standing
voltage
Across the primary
circuit and chassis
No abnormalities when 1500 Vac is applied for 1 minute
Across the primary and
secondary circuits
L/ ML/ MH type: No abnormalities when 1650 Vac is applied for 1 minute
H type: No abnormalities when 1900 Vac is applied for 1 minute
Across the secondary
circuit and chassis
L/ ML/MH type: No abnormalities when 2300 Vdc is applied for 1 minute
H type: No abnormalities when 2640 Vdc is applied for 1 minute
Insulation
resistance
Across the primary
circuit and chassis
100 MΩ or more (70 % or less) at 500 Vdc
Across the primary and
secondary circuits
L/ ML/ MH type: 100 MΩ or more (70 % or less) at 500 Vdc
H type: 100 MΩ or more (70 % or less) at 1000 Vdc
Across the secondary
circuit and chassis
L/ ML/ MH type: 40 MΩ or more (70 % or less) at 500 Vdc
H type: 40 MΩ or more (70 % or less) at 1 000 Vdc
Accessories
See
p.2.
Electromagnetic compatibility
(EMC)
1
2
Complies with the requirements of the following directive and standards.
EMC Directive 2014/30/EU
EN61326-1 (Class A
3
)
EN55011 (Class A.
3
, Group 1
4
)
EN61000-3-2
EN61000-3-3
Applicable under the following conditions
The maximum length of all cabling and wiring connected to the product
must be less than 3 m.
Safety
1
Complies with the requirements of the following directive and standards.
Low Voltage Directive 2014/35/EU
2
EN61010-1 (Class I
5
, Pollution Degree 2
6
)
1. Does not apply to specially ordered or modified products.
2. Limited to products that have a CE mark. Does not apply unless a core is attached to the J1 connector cable.
3. This is a Class A instrument. This product is intended for use in an industrial environment. This product may
cause interference if used in residential areas. Such use must be avoided unless the user takes special
measures to reduce electromagnetic emissions to prevent interference to the reception of radio and
television broadcasts.
4. This is a Group 1 instrument. This product does not generate and/or use intentionally radio-frequency
energy, in the form of electromagnetic radiation, inductive and/or capacitive coupling, for the treatment of
material or inspection/analysis purpose.
5. This is a Class I instrument. Be sure to ground this product's protective conductor terminal. The safety of this
product is guaranteed only when the product is properly grounded.
6. Pollution is addition of foreign matter (solid, liquid or gaseous) that may produce a reduction of dielectric
strength or surface resistivity. Pollution Degree 2 assumes that only non-conductive pollution will occur
except for an occasional temporary conductivity caused by condensation.
To Next Page
