Basic Features ｜ CONFIG Settings
CONFIG parameter details
The details of CONFIG parameters are provided below.
CF00 (RST) Resets the panel settings
Select this to set the following parameters to their factory default settings (p.136). Then,
press SET twice to execute the reset.
CF01 (BLE) Sets the bleeder circuit
Sets the bleeder circuit (p.76). You can turn the bleeder circuit off when you do not want cur-
rent to be sinked by the internal bleeder circuit, such as when you are charging a battery.
When using master-slave parallel operation or series operation, use the same settings on all
connected units.
You can also specify this parameter when the PWR-01 is being used as a slave unit.
CF02 (PRIO) Output-on startup state
Sets the prioritized operation mode when the output is turned on (p.45).
When used as a slave device, CC is automatically prioritized.
• Output on/ off • Soft start/ stop time (CF04 to CF07)
• Output voltage • Output-on/ off delay (CF08/ CF09)
• Output current • Constant current control using an external
voltage/external resistance (CF10)
• Overvoltage protection • Constant voltage control using an external
voltage/external resistance (CF11)
• Overcurrent protection • External control for turning output on/off (CF14)
• Undervoltage limit • Current/ voltage setting limit (CF22/ CF23)
• Internal resistance (CF03)
Display Description
RST Reset Resets the panel settings
Display Description
DIS Disable The bleeder circuit is turned off.
NORM Normal Normal bleeder (factory default setting)
HYP Hyper Hyper bleeder
Display Description
CV CV CV (constant voltage) is prioritized (factory default setting)
CC CC CC (constant current) is prioritized.
