PWR-01 59
Basic Features ｜ CONFIG Settings
CF03 (VIR) Internal resistance setting (VIR)
Sets the internal resistance (Rint) (p.78). The internal resistance setting range (p.78) varies
depending on the model.
CF04
(
SS.C.R
)
Soft start time (CC mode)
Sets the rise time of the output current (p.39).
You can set the output current to rise gradually.
CF05
(
SS.C.F
)
Soft stop time (CC mode)
Sets the fall time of the output current (p.39).
You can set the output current to fall gradually.
CF06 (SS.V.R) Soft start time (CV mode)
Sets the rise time of the output voltage (p.39).
You can set the output voltage to rise gradually.
CF07
(
SS.V.F
)
Soft stop time
(
CV mode)
Sets the fall time of the output voltage (p.39).
You can set the output voltage to fall gradually.
CF08
(
ON.D
)
Output-on delay setting
You can set the delay from when the OUTPUT key is pressed to when the output actually
turns on (p.38).
Display Description
OFF OFF Variable internal resistance function is not used (factory default setting).
Rint (min) to Rint (max) Rint (min) Ω to Rint (max) Ω
Display Description
0.0 0.0 Disable soft start (factory default setting)
0.5 to 10.0 0.5 to 10.0 Soft start time, 0.5 s to 10.0 s
Display Description
0.0 0.0 Disable soft stop (factory default setting)
0.5 to 10.0 0.5 to 10.0 Soft stop time, 0.5 s to 10.0 s
Display Description
0.0 0.0 Disable soft start (factory default setting)
0.5 to 10.0 0.5 to 10.0 Soft start time, 0.5 s to 10.0 s
Display Description
0.0 0.0 Disable soft stop (factory default setting)
0.5 to 10.0 0.5 to 10.0 Soft stop time, 0.5 s to 10.0 s
Display Description
0.0 0.0 No delay (factory default setting)
0.5 to 99.9 0.5 to 99.9 Output-on delay time, 0.5 s to 99.9 s
