130 PWR-01
Specifications ｜ Common specifications
Other functions
400W model 800W model 1200W model
Output-on/ off delay
Setting range: 0.0 s, 0.5 s to 99.9 s
1
setting resolution: 0.1 s
Soft start and soft stop
Setting range: 0.0 s, 0.5 s to 10.0 s
1
?setting resolution: 0.1 s
Overcurrent protection (OCP) activa-
tion delay
Setting range: 0.0 s to 2.0 s
1
?setting resolution: 0.1 s
Preset memory Up to three sets of the following settings can be saved: the set voltage,
the set current, the set OVP, the set OCP, and the set UVL.
Key lock Locks the operation of all keys other than the OUTPUT key.
CONFIG shortcut Up to three CONFIG parameters can be registered to the SC1, SC2, and
SC3 keys.
Sequence Number of programs: 1
Number of steps: 64
Repetition count: 1 to 99998, INFinity
Number of configurable interval loops: 16
Number of interval loops: 2 to 99998
Step time: 0.1 s to 100 h (common to step transition and ramp transition)
Synchronized Operation Synchronization of voltage and current settings, synchronization of the
resumption of steps in a sequence program
Master-slave parallel operation
2
Up to three units (same models) including the
master unit
Up to two units (same
models) including the
master unit
Series operation
3
Two units (the same model)
Multichannel
(VMCB)
Connection
between the mas-
ter unit and PC
LAN, USB, RS232C
Connection with
slave units
LAN
1. Factory default is 0.0 s.
2. Current difference between the master and slaves is 5 % (TYP).
3. H type is excluded.
