PWR-01 53
Basic Features ｜ Protection functions and Alarms
Current setting limit
The maximum current that can be set is limited to about 95 % of the OCP trip point to prevent
OCP activation due to mistaken operations.
By factory default, the current setting limit is set to on (CF22: ON).
If you enable the current setting limit when the current setting is higher than 95 % of the OCP
trip point, the current setting is retained, but the OCP trip point is changed to 105 % of the
current setting.
Power limit (POWER LIMIT)
This function limits the output power to a value that is approximately 105 % of the rated out-
put power. This function changes the output voltage or output current according to the
changes in the load resistance (p.41).
When the output limit function has been activated, the ALM LED blinks (p.46).
400W 800W 1200W
Power limit 420 W 840 W 1260 W
