68 PWR-01
Basic Features ｜ CONFIG Settings
CF72 (BAUD) RS232C baud rate
Sets the baud rate of the RS232C interface.
This parameter is applied when you turn the POWER switch off and on.
CF80 (PROG) Program’s user code display (execute)
Displays the user code for identifying the sequence program.
Press SET twice to execute the sequence program.
CF81 (REM.L) Remaining program repetition count display
Displays the remaining repetition count of the sequence program in execution.
CF82 (REM.T) Remaining program time display
Displays the remaining time of the sequence program in execution.
Display Baud rate
1.2 1.2 1200 bps
2.4 2.4 2400 bps
4.8 4.8 4800 bps
9.6 9.6 9600 bps
19.2 19.2 19200 bps (factory default setting)
38.4 38.4 38400 bps
57.6 57.6 57600 bps
115.2 115.2 115200 bps
Display Description
NONE None Sequence program not written (factory default setting)
0000 to 9999 0000 to 9999 Set user code
Display Repetition Count
---- - - - - Sequence program not running
0 to 9999 0 to 9999 0 times to 9999 times
MORE More 10000 times to 99998 times
INFI Infinity Infinite
Display Remaining time
---- - - - - Sequence program not running
59S to 1S 59 s to 1 s 59 seconds to 1 minute
59 M to 1M 59 m to 1 m 59 minutes to 1 minute
999 H to 1H 999 h to 1 h 999 hours to 1 hour
MORE More 1000 hours or more
INFI Infinity Infinite
