2 GENERAL
This manual provides all information necessary to safely and predictably operate the
system for its intended purpose. All Operators should read and be familiar with
the sections of this manual indicated below next to the green bar before
attempting operation of the system. All sections should be read before
attempting any service or troubleshooting of the system. This is what is included
in this document package:
Maintenance & Troubl
eshooting
This manual covers the safe operation of this
machine and describes the various safety systems
incorporated into the machine.
This manual provides information regarding the
installation of the unit to ensure that the system is
installed, adjusted, and connected correctly.
A brief description of each module on the system
and descriptions of the controls on the HMI
screens. Loading raw materials and machine
preparation. is covered at the end of this section.
INSTALLATION OF
OPTIONAL
FEATURES
Installation of the support spindle, automatic roll
feed, card guide, and output chute guide is
covered here. Adjustment of the optional
registration sensor is also described in this
section.
Maintenance schedules and procedures and
details on moving assemblies for access.
Procedures to adjust machine hardware. Do not
attempt any troubleshooting activities beyond
those described in this section without advice from
a Kinematic Automation Service Representative.
More information is included as separate files in the documentation package.
• Spare Parts List
• Support Documentation: BOMs and Assembly Drawings
• Schematics: Electrical and Pneumatic
• Third Party Equipment Manuals and Instructions
