Matrix 2360 Programmable Shear User Manual - Section 4
12-092600 A 17
4.4 Foot Switch Connector
The foot switch connects to the
equipment through the nine pin
connector on the left side of the system.
The foot switch is optional. It performs
the same function as the CYCLE
pushbutton on the control panel.
4.5 Decommissioning/Disposal
Prior to permanent disposal of the system, perform the following activities:
• Cut all wiring.
• Remove shear blade (See Section 7.3) and wrap it securely to prevent the
sharp edge from being a hazard.
• Remove the PLC battery and dispose of appropriately.
• Dispose of unit according to all requirements of your company and federal,
state, and local authorities.
Other than the blade and battery, this machine contains no hazardous components
that require special disposal.
