Matrix 2360 Programmable Shear User Manual - Section 7
86 12-092600 A
Fuse Designation &
Location
1FU and 2FU are in power entry
module.
Bussmann GDB-5, 5 amp, 5 X 20 mm, fast acting
3FU is in a Dinrail-mounted fuse block
on the left side of the PCB. It supplies
120 VAC to the DC power supply.
Littelfuse 2118-5A 5 amp, 5 X 20 mm, SLO-BLO
4FU is on the upper left of the PCB. It
supplies +24 VDC to the PCB.
Bussmann GDB-5, 5 amp, 5 X 20 mm, fast acting
5FU is in the Dinrail on the right hand
side. It supplies the static control bar.
Bussmann GDA-1A, 1 amp, 5 X 20 mm, fast acting
Replacement fuses may be purchased locally.
