KLS Martin group marLED E3 - DIP switch SW1 marLED for Terminating Resistor

Service Manual
Operating Lights marLED® E3, E9, E9i, E15, battery and
marLED® E3 on ceiling tube Ø 110 mm
50 Revision 2
SW6: Configuration marLED®
DIP OFF ON
3 Reserve, currently ineffective Reserve, currently ineffective
4 No level-selection boost Level-selection boost for marLED® E9/E15
5 Light field size setting via sensoGrip (presetting) Color temperature setting via sensoGrip
7 without surgiCam daughterboard surgiCam daughterboard active
Current DIP switch assignment from HW 40
DIP 6 DIP 8 Configuration E9/E9i/E15
OFF OFF Boost function available (E9 up to HW 39, E9i from HW 40)
ON OFF No boost function available (E9i up to HW 39)
OFF ON E15
ON ON Avoid – leads to malfunction!
6.4.3 DIP switch SW1 marLED® for Terminating Resistor
DIP 1 DIP 2 Terminating resistor R
A
OFF OFF OFF – mandatory with surgiCam daughterboard
ON OFF ON
OFF ON ON
ON ON ON
To switch on the terminating resistor, see
• section 6.1.6 “Terminating Resistor S1 without Coupler”, page 32
• section 6.1.9 “Terminating Resistor S1 with Coupler”, page 34
Restart required if settings have been changed!
If
the CAN address or DIP switch settings have been changed or components have been disconnected or
connected, the entire light system must be restarted to make the changes effective:
•
Switch power off and on again.
– The new settings are now effective.
