Service Manual
Operating Lights marLED® E3, E9, E9i, E15, battery and
marLED® E3 on ceiling tube Ø 110 mm
80 Revision 2
• Remove the 4 central screws (2).
• Turn round the entire light head, making sure
that the cover (1) of the light points upwards.
• Lift the light cover (1) off the light head.
The control electronics board (3), the gasket (2) and
the other components arranged in the bottom
shell (1) of the housing are now freely accessible.
