Chapter 1 Display and Operation MDC-7000/7900 Series
0093169010-10
1-10
17
PANEL key
Control panel brilliance adjustment
18
VRM/PANEL knob
Adjust VRM1,VRM2 or panel brilliance
19
PI lamp
Status lamp of parallel index lines
20
ERBL key
Electronic range and bearing line on and off
21
OFF key
Erase heading line, stop alarm sound, etc.
22
MENU key
Turn MENU on and off
23
ACQ key
Start manual TT acquisition
24
ENT key
Key most often used to make a selection
25
RANGE key
Change radar range scale.
26
MODE key
Change display mode HU/NU/CU
27
OFF CENT key
Off center mode on and off
28
TRACKBALL
Used to make MENU selection and move cursor
