MDC-7000/7900 Series Chapter 2 Radar Basic Operation
0093169010-10
2.29 Pulse width
This radar can change pulse width of the transmission from 0.25NM to 12NM range scale.
SP and LP pulse width can be set separately.
The pulse width in use is displayed at the upper left of the display, using the indications shown in the
table below.
1 Press MENU key to display “Menu”.
Select [ECHO] => [PULSE WIDTH] => select range scale (0.25 to 12 NM) => select [SP] or [LP]
=> set pulse width, and press ENT key.
6kW / 12kW
Range
0.125 S1 S1
0.25 S1 S2 S1 S2
0.5 S1 S2 M1 S1 S2 M1
0.75 S1 S2 M1 M2 S1 S2 M1 M2
1.5 S1 S2 M1 M2 M3 S1 S2 M1 M2 M3
3 S2 M1 M2 M3 L1 L2 S2 M1 M2 M3 L1 L2
6 M2 M3 L1 L2 M2 M3 L1 L2
12 L1 L2 L1 L2
24 L2 L2
32 L2 L2
48 L2 L2
64 L3 L3
25kW
Range
0.125 S1 S1
0.25 S1 S2 S1 S2
0.5 S1 S2 M1 S1 S2 M1
0.75 S1 S2 M1 M2 S1 S2 M1 M2
1.5 S1 S2 M1 M2 M3 S1 S2 M1 M2 M3
3 S2 M1 M2 M3 L1 L2 S2 M1 M2 M3 L1 L2
6 M2 M3 L1 L2 M2 M3 L1 L2
12 L1 L2 L1 L2
24 L2 L2
48 L2 L2
96 L3 L3
S1
(Short pulse 1)
S2
(Short pulse 2)
M1
(Medium pulse 1)
M2
(Medium pulse 2)
M3
(Medium pulse 3)
L1
(Long pulse 1)
L2
(Long pulse 2)
L3
(Long pulse 3)
