Koden MDC-7010 - Setup USER1 and USER2 Color

MDC-7000/7900 Series Chapter 2 Radar Basic Operation
0093169010-10
2-33
Setup USER1 and USER2 color
1 Select the mode (Day or Night) by pressing DAY/NIGHT key, color palette of which you would like
to change.
2 Press MENU key to display “Menu”.
Select [BRILL] => select [USER1] or [USER2].
After selecting the each item, and after adjusting each item with trackball, press ENT key.
You can change the following item's color.
ECHO:
TRAIL:
BKGND PPI:
BKGND DATA:
DATA:
SCALE:
OS TOOL:
TGT:
COAST LINE:
NAV LINE:
ROUTE:
EVENT MKR:
AREA:
PAST TRK:
MONITORED ROUTE:
LAT/LON LINE:
GPS BUOY:
CURSOR:
CHART LAND:
DEPTH:
<R>
<G>
<B>
Black
0
0
0
Blue
0
0
255
Green
0
255
0
Light blue
0
255
255
Red
255
0
0
Pink
255
0
255
Yellow
255
255
0
White
255
255
255
Orange
255
152
0
Dark blue
0
0
128
Grey
128
128
128
Combination of representative colors
