Koden MDC-7010 - 2.21 Function key usage

MDC-7000/7900 Series Chapter 2 Radar Basic Operation
0093169010-10
2-39
2.21 Function key usage
For quick function access, there are six dedicated function keys provided on this radar (“F1”, “F2”, “F3”,
“F4”, “F5” and “F6”).
You can switch to a pre-specified function by pressing each key.
1 Press MENU key to display “Menu”.
Select [MAINTENANCE] => [STARTUP] => [FUNCTION KEY] => [F1] key => press ENT key and
after selecting the setup value.
2 Follow procedure (1) to setup keys [F2], [F3], [F4], [F5] and [F6] by selecting each item and press
ENT key.
3 Another way to setup each function key is to press and hold desired key until menu selection
shows up on the right of the display. Using trackball and ENT key make a selection and save to
designated function key.
PICTURE MODE
PROCESS
Dedicated function name EXPANSION
IR
F1
>
VID
F2
>
OFF NOISE REJ
F3
>
ECHO > SART TRAIL T/REL
F4
>
TRAIL > TRAIL TIME
F5
>
DISPLAY > STAB MODE TRAIL RESET
F6
>
ALARM > TM RESET
TARGET > C UP RESET
NAV TOOL > FERRY MODE ECHO ALARM
MAP > ECHO ALARM EDIT
SYSTEM > VECT T/REL MAP AREA ALARM
VECT TIME GUARD ZONE
CPA/TCPA GUARD ZONE EDIT
PAST POSN T/REL NAV LINE CROSS
PAST POSN TIME
AUTO ACQ AREA
AUTO ACQ AREA EDIT
OS PAST TRK RESET
AIS
TT DELETE
TT ALL DELETE
ACQ
TT REF ACQ RR
ANCH TRUE BRG T/REL
ANCH REL GUARD LINE
SHIP OUTLINE
OWN TRACK STERN LINE
OS PAST TRK REC BARGE ICON
TARGET TRACK
MAP DISP
CHART
EVENT CURSOR
EVENT OWN
TLL OUT
TIME
ASSISTANT DISP
TGT LIST SORT
VECT TIME
