Chapter 2 Radar Basic Operation MDC-7000/7900 Series
0093169010-10
2-56
2.36.3 ROTATION SPEED
This function is to set the rotation speed of the radar echo images, trails, maps and c-map chart when
the ship’s bearing has changed.
1 Press MENU key to display “Menu”.
Select [DISPLAY] => [ROTATION SPEED] => select [FAST], [MEDIUM] or [SLOW], and press ENT
key.
Selection value: FAST, MEDIUM, SLOW
2.36.4 LOCATION INFO
This function displays the line from the own ship position to WPT or LAT/LON position, and displays the
mark on that position.
1 Press MENU key to display “Menu”.
Select [DISPLAY] => [LOCATION INFO] => select [OFF], [WPT] or [LAT/LON], and press ENT key.
WPT: It is necessary to input WPT data (RMB, BWC or RTE and WPT) from navigation device.
LAT/LON: The position data of [LOCATION INFO] => [LAT] and [LON] is displayed.
2.36.5 BIRD VIEW
Bird view image is displayed on the assistant display area. Refer to 1.1 Rader display “Assistant
display”.
This function sets the details of the bird view function.
1 Press MENU key to display “Menu”.
Select [DISPLAY] => [BIRD VIEW] => select [VIEW AREA DISP], [VIEW HEIGHT], [VIEW POINT],
[FRAME POINT], [FRAME LEFT/RIGHT] or [EXPANSION].
After adjusting each item with trackball, press ENT key.
VIEW AREA DISP: Set on or off of the indication of the VIEW AREA on the radar display.
This menu will be active when BIRD VIEW display is selected.
VIEW HEIGHT: Set height value. (50 to 500)
VIEW POINT: Set view point value. (50 to 500)
FRAME POINT: Set frame point. (20 to 200)
FRAME LEFT/RIGHT: Set frame position. (-200 to 200)
EXPANSION: Set expansion of the BIRD VIEW image. (ON or OFF)
