Chapter 2 Radar Basic Operation MDC-7000/7900 Series
0093169010-10
N-UP or C-UP TM mode is selected, own ship position moves to opposite side of heading direction,
and begins to show the true motion image. When own ship position reaches center of the range
scale, own ship position is to reset to the course over water or to the opposite direction of the
course over ground.
Reset true motion
Own ship display position can be manually reset when in true motion operation at any given point, by
following procedure.
Press MENU key to display “Menu”.
Select [DISPLAY] => [TM RESET], and press ENT key.
Antenna position direction and relocatable are in TM
Heading line
TM reset position
