TORQUE CONVERTER REMOVAL
7B - 6
5. From inside of engine compartment relieve tension off of tie
down rod (1) and compression ball (2). Disconnect mounting
bracket (3) hardware and remove bracket, rod and ball. Repeat
for opposite side.
6. Remove air inlet cap (1) from inlet pipe. Remove hood rear
mounting hardware (2).
7. Install eye bolts to hood and attach hoist.
8. Remove hood from machine.
9. Remove front (1) and side (2) floor mat retainer angles from
each side of machine.
10. Remove floor mat.
11. Remove floor plate.
To Next Page
