TRANSMISSION/STEERING VALVE TRANSMISSION

7C - 133

REMOVAL

WARNING

Be sure blade and any rear mounted equipment has been

lowered to the ground or on suitable blocking. Turn the

master switch to the off position and remove key.

1. Open battery door. Remove inner pin and remove door from

battery box.

2. Remove battery hold down clamp and hardware.

3. Remove battery and position on wooden blocks.

4. Remove battery mounting pad.
