PUMPS EQUIPMENT PUMP
10A - 16
REMOVAL
WARNING
Be sure blade and any rear mounted equipment has been
lowered to the ground or on suitable blocking. Turn the
master switch to the off position and remove key.
1. Drain hydraulic reservoir. Refer to the OPERATION & MAINTE-
NANCE MANUAL.
2. Remove front (1) and side (2) floor mat retainer angles from
each side of machine.
3. Remove floor mat.
4. Remove floor plate.
5. Using rolling floor jack, remove transmission guard from under
machine.
To Next Page
