BEARING CARRIER
STEERING DRIVE
7E - 45
8.
Heat bearing cone (11) to 1
35
E
C (275
E
F) for 45 minutes. Install
on
bearing carrier (12) and bottom. To insure cone is seated
,
keep pressure against cone until it cools.
REMARK
For installation of brake ca
rrier, refer to REASSEMBLY and follow
steps from brake carrier installation to end.
340
342
