FRONT IDLER
14 - 13
2.
3. Remove bottom wear bar and shims.
Drive roll pin (9) from mounting support (8).
5. h eye bolts and hoist to mounting support (8). Pry up on suppor
while carefully applying hoist. This is necessary to overcome dra
caused by o-ring inside support.
6.
