RADIATOR COOLING
6 - 25
33. Install air inlet cap (1) to inlet pipe. Install hood rear mounting
hardware (2) loosely.
34. From inside of engine compartment, install hood tie down
brackets (3). Torque bolts to 10 NCm (8 lbf ft) ±10%. Install hook
rod (1) and ball (2) to hood and bracket and tighten nut until ball
compresses. Repeat for other side. Torque hood rear mounting
hardware to 92 NCm (70 lbf ft) ±10%.
35. Install engine left side door. Torque bolts to 38 NCm (28 lbf ft)
±10%.
36. Install engine right side door. Torque bolts to 38 NCm (28 lbf ft)
±10%.
37. Fill the cooling system per the OPERATION & MAINTENANCE
MANUAL.
