Machine Configuration (continued)
2-4
Internal Machine Items
1 Toner cartridge holds toner and is to be replaced when supplying toner.
2 Toner unit holds the toner supply.
3 Conveyance fixing unit passes the paper through the drum unit, and fuses the
toner onto the copy paper, and is to be withdrawn for removal of mishandled
paper.
4 Lever A can be moved to withdraw the conveyance fixing unit for removal of
mishandled paper.
5 Drum unit forms the copy image.
6 Fixing unit fuses the toner onto the copy paper.
7 Reset switch used only by service representative turns machine power on/off
when pressed.
1 Toner cartridge
2 Toner unit
3 Conveyance fixing
unit
4 Lever A
5 Drum unit
6 Fixing unit
7 Reset switch
