Konica Minolta 7085 - FS-111;FS-211 Finisher

Machine Configuration (continued)
2-6
FS-111/FS-211 Finisher
1 Finisher door opens to the internal Finisher to allow clearing mishandled paper
and replenishing staples.
2 Booklet mode outlet (FS-211 Finisher only) outputs finished copied sets when
selecting Fold mode or Stitch & Fold mode.
3 Booklet tray (FS-211 Finisher only) holds sets output in Fold mode or Stitch &
Fold mode.
4 Primary (Main) tray holds sets output in Non-sort mode, Sort mode (offset),
Staple-sort mode, or Group mode (offset).
5 Secondary (Sub) tray holds sets output in Non-sort mode or Group mode with
face down/up mode.
6 Secondary (Sub) tray cover opens to allow clearing mishandled paper.
1 Finisher door
1 Finisher door
6 Secondary (Sub) tray cover6 Secondary (Sub) tray cover
2 Booklet mode outlet
3 Booklet tray
4 Primary
(Main) tray
4 Primary
(Main) tray
5 Secondary
(Sub) tray
5 Secondary
(Sub) tray
FS-211 Finisher
FS-111 Finisher
