Kurz B Series User Manual

KurzB‐SeriesOperationsGuide 4–45
Program ModeAdvanced Setup
Changing to Another Gas Curve Automatically Through the External Input
BeforesettingupOption17fortheexternalinput,youmustdefineOption20touse
CAL DATA SWastheexternalinput.
ToaccesstheExternalInputSetupoptioninProgrammode:
1> PressP.
2> EntertheAdvancedaccesscode,andthenpressE.
3> Press 2toinvoketheQuickJumpoption.
4> Press20fortheExternalInputUsagemenu,andthenpressE.
5> SelectCALDA TASW.
Thepromptreturnstothemainmenu.
ChangingtoanothercalibrationcurveusingAutomaticmodefromanexternalinput:
1> PressP.
2> EntertheAdvancedAccesspassword,andthenpressE.
3> Press 2toinvoketheQuickJumpoption.
4> Press17fortheCalibrationCurveSelectionmenu,andthenpressE.
Thepromptforconfiguringthesourceofthegascalibrationcurveappears.
CURVE SEL MODE
>EXT INPUT LEV^v
5> UsethearrowkeystoselectEXTINPUTLEV,andthenpressE.
Themolecularweightandcalculateddensityoftheactivegascurveappears.
MOLWT 28.997
KG/M3= 1.157254
6> PressEtoreturntothemainmenu.
