Kyocera FS-1030D - Machine Cross Section

2G6
1-1-5
Cassette, MP tray
Optional paper feeder
Switchback and refeed (duplex printing)
Paper path
Option
paper feeder
Printer







1-1-3 Machine cross section
1. Cassette
2. Paper feed unit
3. MP tray
4. MP tray paper feed unit
5. Process unit
6. Toner container
Figure 1-1-3
7. Transfer section
8. Fuser unit
9. Output tray
10. Conveying section
11. Refeed unit
