Kyocera FS-1030D

2G6
1-1-3
Figure 1-1-1
1-1-2 Name of parts
(1) Overall
1. Top cover
2. Front cover
3. Process unit
4. Toner container
5. Main charger cleaner
6. Cassette
7. Paper stopper
8. Output tray
9. MP tray
10. Extension tray
11. Power switch
12. Memory cover
13. Rear cover
14. Optional interface slot
15. Parallel interface connector
16. USB interface connector
17. Operation panel
18. AC inlet


















