2G6
1-6-25
(4) Removing the fuser thermistor
1. Remove and split the fuser unit (See page 1-6-19).
2. Remove the heater lamp (See page 1-6-22).
3. Remove the heat roller (See page 1-6-23).
4. Remove one screw.
5. Remove the fuser thermistor.
Figure 1-6-26 Removing the fuser thermistor
Screw
Fuser thermistor
To Next Page
