Kyocera FS-1030D

2G6
1-5-2
(2) Self diagnostic indication
1-5-2 Self-diagnosis
(1) Self-diagnostic function
Service errors are represented by the alternating flashing of the indicators (LEDs). Each error is represented by the notation
of four digits code and can be monitored on the Remote Operation Panel utility. e.g. Call service 2000 is for the main motor
error.
Printer indicators
(Off)
(Off)
(Off)
(Off)
Green
Red
(Lit)
(Lit)
(Lit)
(Lit)
Figure 1-5-3 Self diagnostic indication
