2G6
1-6-3
1-6-3 Removing the principal outer covers
(1) Removing the top cover/output tray
1. Open the top cover.
2. Remove two screws.
3. Remove the top cover/output tray.
Figure 1-6-2 Removing the top cover/output tray
Screws
Top cover
Top cover/output tray
