Kyocera FS-1030D

2G6
1-7-1
Figure 1-7-1 Firmware program data format
1-7-1 Upgrading the firmware on the main PWB
Updating the system (controller) firmware is possible by downloading the firmware through the parallel interface or through
the memory card (CompactFlash). These firmware programs are directly overwritten in the system DIMM (Flash ROM type
only) on the main PWB. The operation panel message in different languages can also be downloaded through the parallel
interface or through the memory card.
(1) Firmware program data format
System firmware
The data to be downloaded are supplied in the following format:
Firmware description (supplement)
Firmware description 1: Engine controller
2: MFP controller
3: Printer (Main) controller
4: Facsimile
5: NIC
6: Operation panel message language
7: Panel language
Product code 2G6: This printer
Software ID
Build number
0: Normal
E: Corrective
Pause (under bar)
Pause (period)
Compression
Destination
S2G6_3000001021.cmp
Version up history
