General Maintenance 63
8. Remove the hopper divider guard (see Figure 3-27).
9. Take the floating panel out of the hopper with an appropriate lifting device. To do so:
9 a. Remove the 4 bolts that secure the floating panel to the front hopper posts (2 on each side).
Figure 3-57
Floating panel
9 b. Pull the handle (see Figure 3-58) to open the panel mid-way.
Screws (4)
