Learjet
60
Pilot's
Manual
"
The
bleed-air
shutoff
valve
closes
"
The
wing
anti-ice
bypass
circuit
is
deactivated
"
The
EMER
PRESS
annunciator
illuminates
The
result
is
that
engine low-pressure
bleed
air
is
ducted
directly into
the
cabin
air
overhead
and
floor
diffusers
.
This
bypasses
all
bleed-air
plumbing
in the tailcone
area
and
will
stabilize
cabin
altitude
if
the
pressurization
failure
has
occurred
in
that
area
.
The
emergency
pres-
surization
valves
are
energized
to
the
open
position
and
de-energized
for
normal
bleed-air
flow
.
Each
valve
is
independent
of
the
other
and,
whenever
both
valves are
open, temperature
control
and
bleed
air
for
wing
and
windshield
anti-ice
will
be
unavailable
.
Operating
power
for
emergency
valve
actuation
is
28
VDC
supplied
through
the 7
.5-
amp
L and
RBLEED
AIR
circuit
breakers
on
the
pilot's
and
copilot's
circuit
breaker
panels
.
PRESSURIZATION
CONTROLS
AND
INDICATORS
MODE
SWITCH
The
MODE
switch
is
an
alternate-action
switch
located
on
the
copi-
lot's
switch
panel
.
The
switch
is
used
to
toggle the
pressurization
sys-
tem between
the
automatic
and
manual
modes
.
Upon
initial
power-
up, the
system
will
be
in
automatic
mode
if
no
faults
were
revealed
in
the
self-test
.
If
a fault
is
detected,
the
system
will
revert to
manual
and
the
FAULT
annunciator
(part
of
the
MODE
switch)
will
illuminate
.
To
switch
from
automatic
to
manual
mode
and
vice
versa,
the
MODE
switch
is
depressed
and
released
.
When
manual
mode
is
selected, the
MANUAL
annunciator
(part
of
the
MODE
switch)
will
be
illuminated
.
MAN
ALT
CONTROL
The
MAN
ALT
control
is
a
3-position
valve
located
on
the
copilot's
switch
panel
.
The
control
is
used
to
direct
either
regulated
vacuum
or
cabin
pressure
to
the
outflow
valves
positioning
them
so
that
the de-
sired
cabin
altitude
results
.
Moving
the
control
to
the
UP
detent ap-
plies
regulated
vacuum
to
the
outflow
valves
causing
them
to
move
toward
the
open
position
and
increasing
cabin
altitude
.
Moving
the
control
to
the
DN
detent
applies
cabin
pressure
to
the
outflow
valves
causing
them
to
move
toward
the
close
position
and
decreasing
cabin
altitude
.
When
the
control
is
in
the
center
position,
the
outflow
valves
PM-123
6-27
Original
