Pilot's
Manual
LANDING
GEAR
SELECTOR
SWITCH
The
LANDING
GEAR
switch,
located
on
the
center
instrument
panel,
is
a
lever-lock
type switch
and
must
be
pulled
aft
before
selecting the
UP
or
DN
position
.
The
switch
controls
the
position
of
the
gear
selec-
tor
valve
and
the
door
selector
valve
through
gear
and
door
position
switches
.
Electrical
power
for
the
control
circuits
is
28
VDC
supplied
through
the
2-amp
GEAR
circuit
breaker
on
the
copilot's
circuit
breaker
panel
.
The
landing
gear
control
circuits
are
operative
during
EMER
BUSmode
.
Landing
gear
retraction
cycle
:
When
the
LANDING
GEAR
switch
is
placed
in
the
UP
position
and
the
squat
switches
are
in
the
air
mode,
the
following
sequence
of
events
will
occur
:
1
.
28
VDC
will
be
applied
to
the
"open"
solenoid
of
the
door
selec-
tor
valve
and
hydraulic
pressure
will
be
applied
to
both
inboard
main
gear
door
uplock
actuators
and
door
actuators
.
2
.
When
the
inboard
main
gear
doors open,
door
open
switches
will
complete
a
circuit
from
the
LANDING
GEAR
switch
to
the
"up"
solenoid
of the
gear
selector
valve
.
Hydraulic
pressure
will
be
applied
to
the
main
and
nose
gear
actuators
and
the
gear
will
retract
.
3
.
When
the
main
gear
retract,
gear
up
switches
will
complete
a
circuit
from
the
LANDING
GEAR
switch
to
the
"close"
solenoid
of the
door
selector
valve
.
Hydraulic
pressure
will
be
applied
to
the
inboard
main
gear
doors
actuators
to
raise
the
gear
doors
.
Additionally,
a
gear
down
safety
switch
will
complete
a
circuit
to
the
"up"
solenoid
of the
gear
selector
valve
to
maintain
con-
tinuous
hydraulic
pressure
in
the
gear
actuators
.
4
.
The
gear
doors
are
latched
by
uplatch
actuator
spring
tension
.
PM-123
3-7
