Lenze i750 - Components for Operation in the DC−Bus Connection; DC Infeed Adapters

Components for oper
aon in the DC−bus connecon
DC infeed adapters
DC power supply adapter i700 E70AZEVE001
The "DC power supply adapter i700" enables the touch-safe connecon of one or two single
cores with ring cable lugs to the DC busbar system.
Mounng is possible on the le or right side of the suppliers and axes.
Applicaon ar
eas
•
Distribung the installaon over several rows, groups or control cabinets
•
Connecng the regenerave power supply module of the "Servo Drives 9400" device
series
•
Connecon of other wired components to the busbar system
Dimensions
106.040.0
57.0
<21.0
ø 6.5
ø <10.0
<4.0
E70AZEVE001 Ring cable lugs, single cores
All dimensions in mm
DC power supply adapter i700
Order code E70AZEVE001
Connecon descripon Touch-proof c
onnecon of single cores to the DC busbar system
Max. ampacity A 120
Connecon type Screw M6
Max. cable cross-secon
Single core mm² 35
Single core AWG 2
2 single cores mm² 25
2 single cores AWG 2
Tightening torque Nm 5
Tightening torque lb-in 44.3
Required tool Crossp screwdriver PH3
Accessories
Componen
ts for operaon in the DC−bus connecon
DC infeed adapters
