Lenze i750 - Power Supply Units

Power supply units
For the external supply of the control electronics of the inverter.
The par
ameterizaon and diagnoscs can be executed when the mains input at the inverter is
deenergized.
Order code EZVA024
005BB000000 010BB000000 005FB000000 010FB000000 020FB000000
Mains c
onnecon 1 AC 230/240 V 2 oder 3 AC 400/480 V
Netzspannungsbereich V 85 ... 277 360 ... 575
Rated current A 1 1.5 0.3 0.4 0.85
Rated output voltage V 24
Ausgangsspannungsbereich V 22.5 ... 29.5
Rated output current A 5 10 5 10 20
Degree of protecon IP20
Abmessungen (H x B x T) mm 130 x 40 x 125 130 x 60 x 125 130 x 40 x 125 130 x 60 x 125 130 x 70 x 150
Weight kg 0.86 1.05 0.78 1.32 1.6
Accessories
P
ower supply units
