2-66 Service Manual
7002-xxx
201 .94 Expected wide page not
detected by narrow
media sensor, possible
accordion jam. Fuser
page count is not
available.
• Page did not enter or exit fuser nip
cleanly.
• Narrow media sensor not functioning
correctly.
• Actual page is narrow when wide
page was expected.
• If label media, ensure front
edge meets 1/8 inch
requirement.
• Check the fuser for wear or
contamination. If a problem
is found, replace the fuser
assembly. See “Fuser
assembly removal” on
page 4-79.
• If media is narrow, then turn
off first sheet detection (In
Diagnostics Menu,
PRINTER SETUP, Engine
Settings 3. Select 16 and
touch Submit).
• The fuser narrow media
sensor may not be
functioning properly. Go to
“Fuser narrow media
sensor service check” on
page 2-139.
202 .00 Paper jam at fuser exit
or redrive area. Fuser
page count between 0
and 99,999.
Page may be jammed in fuser exit or
redrive area.
• Make sure the redrive door
is complete closed.
• Check the fuser for any
signs of wear or
contamination. If any are
found, replace the fuser
assembly. See “Fuser
assembly removal” on
page 4-79.
• Turn media over to reduce
+W curl.
• Check upper redrive
diverter and diverter spring
for any signs of damage, a
loose spring, or binding
parts. Repair the redrive as
necessary.
• Check any installed output
option(s) that may be
installed for correct
installation and alignment.
• The fuser exit sensor may
not be functioning properly.
Go to “Fuser exit sensor
service check” on
page 2-138.
User attendance messages—paper jams and paper handling errors (2xx.xx)
Code
Sub
code
Description Possible causes Action
