Diagnostic information 2-67
7002-xxx
202 .01 Page did not cleanly exit
fuser or redrive area.
Fuser page count
between 0 and 99,999.
Page may be jammed in fuser exit or
redrive area.
• Make sure the redrive door
is complete closed.
• Check the fuser for any
signs of wear or
contamination. If any are
found, replace the fuser
assembly. See “Fuser
assembly removal” on
page 4-79.
• Turn media over to reduce
+W curl.
• Check upper redrive
diverter and diverter spring
for any signs of damage, a
loose spring, or binding
parts. Repair the redrive as
necessary.
• Check any installed output
option(s) that may be
installed for correct
installation and alignment.
• The fuser exit sensor may
not be functioning properly.
Go to “Fuser exit sensor
service check” on
page 2-138.
202 .02 Exit sensor covered too
long. Fuser page count
between 0 and 99,999.
Page may be jammed in fuser exit or
redrive area.
• Make sure the redrive door
is complete closed.
• Check the fuser for any
signs of wear or
contamination. If any are
found, replace the fuser
assembly. See “Fuser
assembly removal” on
page 4-79.
• Turn media over to reduce
+W curl.
• Check upper redrive
diverter and diverter spring
for any signs of damage, a
loose spring, or binding
parts. Repair the redrive as
necessary.
• Check any installed output
option(s) that may be
installed for correct
installation and alignment.
• The fuser exit sensor may
not be functioning properly.
Go to “Fuser exit sensor
service check” on
page 2-138.
202 .03 Page is covering narrow
media sensor during
warm up. Fuser page
count between 0 and
99,999.
If page is not visible from front or rear of
machine, partial piece of page may be
torn off in fuser covering narrow media
sensor. Narrow media sensor or flag may
be dislodged/damaged.
Check the fuser for any signs of
a piece of media stuck in the
fuser.
If the problem recurs, go to
“202.03 Error code service
check” on page 2-95.
User attendance messages—paper jams and paper handling errors (2xx.xx)
Code
Sub
code
Description Possible causes Action
