LG N4B2N - 2 LG Network Storage Installation; Hard Disk Installation and Set up

Follow these instructions to install the LG NETWORK STORAGE. If the LG NETWORK
STORAGE is internal, go to <Hard disk installation and setup>, otherwise go to <LG
NETWORK STORAGE connection>.
Hard disk installation and set up
The LG NETWORK STORAGE hard disk rack is shown below. Refer to each part while
installing the HDDs.
Components of Hard Disk Rack
Safety Lever
Locker Lever
Hard Disk Rack Lever
Hard Disk Rack
Hard Disk Rack Label No.
Note: Hard disks of size 500GB/1TB/2TB are recommended, all of which should
be the same size and of the same company. If the disk sizes dier, the RAID
conguration will use the smallest disk as a reference to measure all disk
sizes,therefore the remainder can not be utilized and durability decreases.
2. LG Network Storage Installation
