• RAID10 Mirroring & striping volumes
In relation to the volume conguring techniques RAID1 and RAID0, the Disks are
congured 2 at a time by RAID1, followed by the congured set being associated
by RAID0 and hence the volume as a whole is congured. With more than 4 Disks
present, conguration occurs in pairs. 4 Disks are used to congure the LG Network
Storage.
If Disk damage does not happen simultaneously to 2 Disks congured through
RAID1, the volume will continue to function. The volume save capacity is equal to
the product of the minimum Disk capacity and half of the number of Disks in the
volume.
Data backup and the safeguarding of saving capacity occur simultaneously. (RAID5
prioritizes capacity security, where RAID10 prioritizes data backup).
