4. LG Network Storage Web Menu Use (for LG
Network Storage administrators)
56
- the ‘syncing’ state refers to the RAID conguration process,
- ‘migrating’ indicates reconguring RAID
- ‘quarter-check’ indicates setting quota for volume
- ‘scanning’ indicates checking volume
- ‘sys_syncing’ indicates conguring the system areas.
5 Capacity (Used/Total)
The amount used and total capacity of volume are displayed. The percentage of
capacity used (Used/Total) is indicated by the bar on left and full capacity (Total) is
indicated by the bar on the right.
Note: Total storage represents total available storage, which is dened by le system and
RAID level. The ext3 le system of the LG NETWORK STORAGE occupies 1.5% of the total
HDD storage, thus the actual available storage in a volume is approximately 98.5% of
the total user storage. When using one HDD per volume (single disk), the total storage is
equal to the actual available storage of a HDD. The total storage of a RAID- based volume
diers according to RAID level (JBOD / RAID0 / RAID1 / RAID5 / RAID10). For JBOD, the total
available storage is the sum of the actual available storage of each HDD. For RAID0, the
total available storage is the actual available storage of the smallest HDD multiplied by
the number of HDDs. For RAID1, the total available storage is the actual available storage
of the smallest HDD. For RAID5, the total available storage is the actual available storage
of the smallest HDD multiplied by (the number of HDDs minus 1). For RAID10, which
is composed of 5 HDDS, the total available storage is twice that of the actual available
storage.
Note:The represented size of the HDDs diers depending on manufacturer and OS.
HDD manufacturers use an exponent of 1000 while OSs such as Microsoft Windows
use exponents of 1024. The total available storage on the LG NETWORK STORAGE is
represented by the exponent 1024.
Note: Volume storage of the LG NETWORK STORAGE is the total HDD storage without the
system area and the swapping area. If for example a volume is congured with a 1TB HDD,
with 1x10
12
bytes of storage, user area will be as follows: 1x10
12
- 10x1024
3
(system area)
- 2x1024
3
(swapping area) = 987115098112 bytes. This becomes 919Gb when converted
using the exponent 1024.
