11. Appendix MX-FR Series Modular Matrix Frames – User's Manual 182
3.3.2
Released: 2012-11-12
▪
3.3.3
Released: 2013-01-17
New feature
▪ CPU SCH version is displayed in the LCD menu (among the Installed cards - both LCD types are
supported)
▪
3.3.4
Released: 2013-01-28
▪ The image was shifted one pixel to the right with digital signals. Affected cards: MX-DVII-HDCP-IB,
MXD-UMX-IB
3.3.5
Released: 2013-03-04
▪ IO card SN numbers may cause stability issues.
3.3.6
Released: 2013-05-23
New feature
▪ MX-TPS-OB, MX-TPS-OB-A, MX-TPS-OB-S support (incl. serial passthru and ethernet functions)
▪ MX-TPS-IB, MX-TPS-IB-A, MX-TPS-IB-S support (incl. serial passthru and ethernet functions)
▪ File uploading to SD card through Lightware protocol. (needed for TPS fw upgrade)
▪ The LCD screen didn't show the analog audio options for the MX-HDMI-3D
▪ If a dynamic EDID memory slot had been empty and new EDID was read from one output, then the
reboot.
▪
output with DVII input.
▪ HDCP keycounter sometimes resulted with 0 key with certain devices due to a short timeout. Now this
▪ The MX-DVII-IB and the MX-UMX-IB boards sometimes didn't detect the 36 bpp - 24 bpp deep color
change, and remained in 36bpp mode.
▪ MX-DVII-IB, MXD-UMX-IB: SPD Infoframe was sent with wrong header, could cause issues with deep
color signal. Stored settings block was too large on these cards.
▪ If an MX-HDMI-3D-IB card was present at the 1st input slot and any output was connected to the 0th
input (ie. disconnected), then the matrix has coninously rebooted.
▪ A noisy incoming signal may disable input ports on MX-HDMI-IB, MX-DVI-HDCP-IB, MX-HDMI-TP-IB
and CPU test input (signals were detected appropriately but not forwarded to the crosspoint). The only
now.
3.3.7
Released: 2013-08-22
New feature
▪
▪
RS232 port utilizes the full bandwidth (depending on the actual baudrate)
▪
the alarm LED.
▪
▪ HDBase-T HDCD database is used to recognise remote devices
▪ The minimum assertion time for hotplug line is 1.5 sec on the MX-HDMI-IB, MX-HDMI-TP-IB, MX-DVI-
HDCP-IB, MX-DVII-IB, MXD-UMX-IB, MX-HDMI-3D-IB (and variants), MX-TPS-IB (and variants) cards and
test input port. This is 15 times greater than the required minimum by the standard. The intention of
this extra long HPD pulse is prevent the non-standard devices to miss the hpd event.
▪ A false "SBTB error" message has appeared on the LCD screen after boot if at least one MX-DVIDL-OB
card was installed in the frame. This issue persisted only with 3.3.6
▪ Changing audio mode on a port could have an effect on the adjacent port's audio mode. Affected
cards: MX-HDMI-3D-IB, MX-HDMI-3D-OB, MX-TPS-IB, MX-TPS-OB.
▪
cases, and still reported embedded audio. Affected cards: MX-HDMI-3D-IB, MX-HDMI-3D-OB, MX-TPS-
IB, MX-TPS-OB
▪ Factory default test pattern changed from solid black to color bar. Affected cards: MX-HDMI-3D-IB, MX-
HDMI-3D-OB, MX-TPS-IB, MX-TPS-OB
▪
IB, MX-TPS-OB
▪
41 MHz TMDS clock) was not detected by the port after unmute. Fixed. Affected cards: MX-HDMI-OB,
MX-DVI-HDCP-OB, MX-HDMI-TP-OB, MX-CPU2 (Preview output).
