Overview 3
Indicator unit
(4) Engine oil pressure indicator/engine oil
level indicator (red)
When engine lubricating oil pressure is too
low, this indicator lights up, and a buzzer
sounds. If in addition the text field (24) shows
the text
Oil with a double arrow pointing
downwards, the engine oil level is too low.
• Insufficient oil in the crankc
ase
• Engine too hot
• Incorrect oil used
• Internal leakage in the lubricati
ng oil circuit
• Top up with motor oil
• Switch off the buzzer with the reset button
(19).
If the "engine protection"* functi
on is activated
and the oil pressure and/or engine o
il level
continues to fall, the truck only mo
ves at
crawling speed (approx. 2 km/h) and
text
field (24) displays:
•
Oil with double downwards arrow and
error code
X201 at low oil level,
• error code
X202 at low oil pressure.
(5) Electrical control system fault
(red)
Lights up when an electrical control system
fault is present, and displays a error code in
text field (24).
(6) Engine temperature indicator (red)
Lights up when the specified tempera
ture limit
is reached. A buzzer also sounds when
the
permissible temperature limit is re
ached. If the
"engine protection"* function is ac
tivated, the
vehicle only moves at crawling speed
(approx.
2 km/h). Error code
X204 is displayed
in text
field (24).
• Fan motor defective
• Thermostatic switch defective
• Water cooler clogged
• Leakage in the coolant circuit
• Coolant level too low
• Switch off the buzzer with the reset butt
on
(19).
(7) Load/overload indicator (special equip-
ment)
Symbol lights up yellow when load is normal.
DANGER
Symbol lights up red when overloaded.
Set down load immediately.
• Consult load diagram.
(8) Particulate filter alarm (red)
Lights up with activated particulate filter con-
trol system, if load period of the particulate
filter exceeds 8.5 h, or if an error in the partic-
ulate filter control system occurs simultane-
ously with the display of an error code in the
text field (24). In addition, the buzzer sounds.
The vehicle only moves at crawling speed.
• Regenerate particulate filter as soon as
possible.
• Correct error in particulate filter control
system.
(9) Level display (yellow) (special equipment)
Lights up when the coolant level is below the
minimum.
• Top up the coolant.
Please contact your authorised dealer.
(10) Hydraulic oil microfilter indicator (yellow)
(special equipment)
Lights up when the microfilter requires main-
tenance.
• Microfilter clogged, change it.
(11) Fuel tank level display (colour depending
on level, green or red)
• Shows the current fuel level.
(13) Symbol for Particulate filter
Lights up if particulate filter control system is
activated.
(14) Operating hours display
Shows the operating hours of the forklift truck.
This indicator is evidence of the fork lift truck’s
operating hours and of the inspection and
maintenance work to be performed.
Operating Instructions – 393 807 1001 EN – 08/2008 21
