4 Operation
Standard equipment
Adjusting the seat angle of tilt (option)
d3921354
8
7
9
¾ Lift the handle (6).
The seat is tilted to the desired
position by
applying or taking off one’s wei
ght simultane-
ously.
Adjusting the seat position (
option)
¾ Lift the handle (9).
The desired position is reached by simultane-
ously sliding the seat forward or back.
Adjusting the backrest extension (option)
¾ Push the backrest extension (7
)upordown
for an individual adjustment.
Turning the seat heating on/off
(option)
¾ Toggle the switch (8) on or off.
NOTE
Long sitting puts excessive strain on the spi-
nal column. Prevent strain with regular, light
exercising.
Adjusting the armrest on the operator’s
seat
NOTE
The armrest on the operator’s s
eat is raised
automatically by spring press
ure after the
handwheel (1) is loosened.
28 Operating Instructions – 393 807 1001 EN – 08/2008
