LNC-Lathe New T6-Series
CNC Operation
4 LNC Technology Co., Ltd.
MDI DATA INPUT AREA
A. CNC Function Keys
Name
Functions
Description
POS
POS
to display positions
PROG
PROG
to edit and to display program (with 1.Edit Mode2.Auto
Mode3.Manual Mode)
OFFSET
OFFSET
to set and to display tool offsest
GRAPH
GRAPH
to draw tool path
DGNOS
DGNOS
to display instance messge at DGNOS page
PARAM
PARAM
to display parameter screen
CNC Function Keys
