Installation Guide
4. Select the “III” tab
5. Select P-iris, and save settings
The focus of the Logipix camera can be set easily with a special configuration
function which you can find in the free SCPlayer software. The function utilizes
the traits of the JPEG2000 compression standard, that more details - with the
same compression -, results a larger image size. Thus the largest image size
means the best quality.
The focus setup must be performed for a zoomed area on the picture!
It is important to choose an area for the focus setup where there are no
moving objects during the setup, moreover there are no significant changes in
light condition.
1. Press F12 button, or choose Camera focus setup at Device settings!
2. Zoom in to the desired part of the picture by the mouse scroll (or
PageUp, PageDown keys), which should be the sharpest area.
3. After the enlarging click on the image or press the Space key! Thus the
current image size will be the maximum (the image size marker on the
left will be at its highest value).
4. Turn the focus ring on one direction cautiously! If there is a decreasing
effect on the image size, turn the focus ring on the other direction.
5. When the image starts to be sharper, the image size starts to increase.
First, the indicator on the left side reaches its maximum, then stays
there. The image size increase can be seen on the lower right corner.
After the sharpest point has been found, the indicator starts to fall. In
this case turn the focus ring on the other direction until the indicator
reaches its maximum again.
Setup the Iris
Rotate the Iris ring of the lens to find the right position!
1. Loosen the Iris fixing screw of the lens! Rotate it counter-clockwise!
2. Rotate the Iris ring of the lens to adjust its position!
13/80
