Installation Guide
Mounting the Hybrid Extender into the rack cabinet
The 1U high Hybrid extender can be mounted in a 19” rack cabinet.
1. Place 4 pieces of M6 cage nuts (2 on each side) on the front columns of
the rack cabinet according to the mounting holes of the Hybrid Extender,
which you can see at the edges of the front panel!
2. Take 2 pieces of screws for the rack cabinet!
