Installation Guide
Hardware installation
According to the designed plan determine the places of each device in the
stadium and install the Ethernet cables between them. Determine the places of
the cameras, the network switches, the LNVRs and Hybrid extenders,
furthermore the Server and the Client workstations! Connect the LNVRs to the
company network (VMS VLAN) by CAT6 cables and connect the cameras to the
Local Network Switches (CAMERA VLAN) by CAT5 cables. Connect the switches
to the LNVRs by CAT6/optical cables (requires additional SFP modules). Ensure
the proper power supplies for the Logipix multi-megapixel fix cameras, Logipix
FullHD fix cameras, the Logipix PTZ cameras, the Logipix Hybrid extenders and
the LNVRs. See the Appendix A at the end of the Hardware installation chapter
of this document!
Take into account some important environmental conditions while determining
the devices' final places!
• Determine places for the cameras, both for the fix multi-megapixel
Logipix cameras and for the Logipix PTZ cameras where they can be
installed safely and properly, where their operation cannot be disturbed
by any meteorological effect (heavy rain, wind or other natural
calamities) or spectator vandalism.
• The LNVRs and the Hybrid Extenders must be installed indoor or in a
heated outdoor box to ensure the proper temperature for operation in
any season which has been specified in the data sheets.
